| Specification | Diameter(mm) | Cap | Length(mm) | Current(A) | Voltage(V) | Power(W) |
UV Intensity (uW/cm2) |
Lifespan |
| G4T5 | 16 | G5 | 135 | 170 | 28 | 4 | >4000 | 8000 |
| G6T5 | 16 | G5 | 212 | 160 | 42 | 6 | >5000 | 8000 |
| G8T5 | 16 | G5 | 288 | 145 | 56 | 8 | >6000 | 8000 |
| G10T5 | 16 | G13 | 330 | 220 | 52 | 10 | >7000 | 8000 |
| G15T5 | 16 | G13 | 437 | 330 | 60 | 15 | >7500 | 8000 |
| G20T5 | 16 | G13 | 589 | 370 | 77 | 20 | >8500 | 8000 |
| G30T5 | 16 | G13 | 894 | 410 | 90 | 36 | >12000 | 8000 |
| G40T5 | 16 | G13 | 1200 | 420 | 106 | 40 | >12000 | 8000 |
| G65T5 | 16 | G13 | 1554 | 425 | 179 | 65 | >12000 | 8000 |
| G100T5 | 16 | G13 | 1554 | 710 | 185 | 100 | >13000 | 8000 |
| G150T5 | 16 | G13 | 1554 | 825 | 210 | 150 | >13000 | 8000 |
Instruction:
Made of Quartz glass and sleeve with silicon seal, Power from 4w to 150w,the length from
Remark:L=standard length of the lamp total lenght= standard length +25mm
